EG4 18kPV All-in-One Hybrid Solar Inverter | 18kW PV / 12kW AC | Split-Phase | 4-MPPT | Scalable | Remote Wi-Fi Monitoring
EG4 18kPV All-in-One Hybrid Solar Inverter | 18kW PV / 12kW AC | Split-Phase | 4-MPPT | Scalable | Remote Wi-Fi Monitoring
SKU: INV024
- Regular price
- Price: $3,700.00
- Regular price
- List Price: $4,352.95
- Sale price
- Price: $3,700.00
- Unit price
- per
Found a lower price?
We'll match any verified competitor price — just share the listing with us before you buy.
Low stock
Couldn't load pickup availability
- Free Shipping on Orders >$5K
- Easy 30 Day Returns
Why Buy From PowerGen Store
Why Buy From PowerGen Store
Authorized Dealer
100% genuine products with manufacturer warranty.
Free Fast Shipping
On most orders across the U.S.
Expert Support
Real people ready to help you choose. Based in USA
Secure Checkout
Safe encrypted payments you can trust.
Easy Returns
Simple returns on eligible orders.
Trusted Nationwide
Customers rely on PowerGen for dependable solutions.
Price Guarantee
Price Guarantee
At PowerGen Store, we are committed to offering you the best prices online. If you find a lower price at another online store within two months of your purchase, just let us know.
Click Here to review full Price Guarantee Policy
Manufactures Warranty
Manufactures Warranty
PowerGen Store is an Authorized Dealer for all of our Suppliers, so every product you purchase includes the Full Manufactures Warranty provided directly by the Manufacturer. See Manufactures Website for More Details
Return Policy
Return Policy
We have a 30-day return policy, which means you have 30 days after receiving your item to request a return.
Click Here to review our full Returns Policy
Shipping Policy
Shipping Policy
At PowerGen Store, we are dedicated to ensuring our customers enjoy a smooth and efficient shipping experience. As a special benefit for our valued customers, we are pleased to offer FREE SHIPPING in the Contiguous 48 United States (See below for Alaska & Hawaii). To guarantee timely delivery of your orders, we have built a comprehensive network of couriers. Please see the detailed information below regarding our shipping Policy.
Click Here to read out full Shipping Policy
PRODUCT DESCRIPTION
Description
The EG4 12K Hybrid Inverter delivers 12,000W of power with up to 18,000W PV input, ideal for large home or off-grid energy systems. Featuring 3 MPPT inputs, built-in breakers, and a fast 15–30ms UPS switch, it ensures seamless, efficient operation. Its transformer-free design keeps it lightweight and energy-efficient while supporting smart load control, AC coupling, and peak shaving to cut energy costs and protect against grid outages. An intuitive LCD touchscreen and remote monitoring make setup and management simple.
Specifications
| Specification | Details |
|---|---|
| AC Voltage | 120V AC / 240V AC |
| AC Frequency | 50 Hz / 60 Hz |
| Nominal Voltage | 51.2V |
| Max Continuous AC Current | 50A @ 240V AC |
| Max AC Input Power | 12,000 W |
| Max AC Bypass | 200 A |
| Operating Voltage Range | 180 – 270V AC |
| Output Voltage | 120V AC / 240V AC |
| Max Continuous Output Current | 50 A |
| Output Power | 12,000 W |
| BMS Cutoff Range | 42 – 47 V |
| Surge Capacity (with PV) | 14,700 W (10 min) / 15,500 W (5 min) |
| Surge Capacity (without PV) | 13,500 W (10 min) |
| Max Continuous Line Wattage | 6,000 W |
| Power Factor | 0.99 (Full Load) |
| Reactive Power Adjustment Range | 0.8 ~ 0.8 Leading Adjustable |
| Total Harmonic Distortion | <5% (Full Load) |
| Transfer Time | 10 – 20 ms (Single) / 20 ms (Parallel) |
| AC Bypass (Generator) | 90 A |
| Max Continuous Line Wattage (per 120V) | 8,000 W |
| Output Frequency | 50 Hz / 60 Hz |
| Max Output Power (with PV) | 14,700 W (10 min) / 15,500 W (5 min) |
| Max Output Power (without PV) | 13,500 W (10 min) |
| Total Harmonic Distortion Voltage | <5% |
| Switching Time | 10 ms |
| Number of MPPTs | 3 |
| Inputs per MPPT | 2 (MPPT 1) / 1 (MPPT 2 & 3) |
| Max Input Current | 25 A (MPPT 1) / 15 A (MPPT 2 & 3) |
| Max Short Circuit Input Current | 31 A (MPPT 1) / 19 A (MPPT 2 & 3) |
| DC Input Voltage Range | 100 – 600 V DC |
| Start-Up Voltage | 100 V DC |
| MPPT Operating Voltage Range | 140 – 500 V DC |
| MPPT Voltage | 360 V DC |
| Max PV Array Power | 18,000 W |
| Max Efficiency | 94 – 99.9% |
| Idle Consumption | ~70 W (Normal) / ~18 W (Standby Mode) |
| Nominal Battery Voltage | 48 V DC |
| Battery Voltage Range | 40 – 60 V DC |
| Max Charge / Discharge Current | 250 A |
| Recommended Battery Capacity per Inverter | >200 Ah |
| Operating / Storage Temperature Range | -13°F – 140°F (-25°C – 60°C) |
| Altitude | <6,561 ft (2,000 m) |
| Relative Humidity | 0 – 100% |
| Typical Noise Emission | 68 dB @ 3 ft |
| Protection Rating | IP65 / NEMA 4X |
| Communications | RS485 / CANBus / WiFi |
| Max Parallel Connections | 10 |
| Weight | 121 lbs (55 kg) |
| Dimensions (H × W × D) | 34.3 × 20.5 × 11.2 in (871 × 520 × 285 mm) |
